Author Topic: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)  (Read 18196 times)

0 Members and 1 Guest are viewing this topic.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« on: September 01, 2012, 11:49:19 pm »
Well, I was deep into the final design stages of my scratch build multicade cabinet when I stumbled across a craigslist ad the other day for a WWF wrestling cabinet.   After doing a double take I immediately recognized it as a Nintendo cabinet of some sorts.  So, a rainy day and $200 later, the WWF Superstars cabinet is sitting in my fathers shop.   I only got about 10 minutes with the cab before I had to leave for the evening to go to my brothers house for our fantasy football draft.  I did get a chance to turn the machine on and check the monitor and also get some pictures.

The monitor is in great shape.  It is nice and bright and does not have any noticeable burn in.  The inside of the cabinet is actually pretty clean and mostly orderly.  The board in there is a Jamma board for what it is worth and it looks like there are some converters of some kind in there as well.  I am new to all of this so I am pretty ignorant to all of the innards and have a lot of research and learning to do.  I also need to learn how to work on the monitor without electrocuting myself as well :)

After looking up the model numbers on the back of the cabinet, it seems this cab started life out as a blue Donkey Kong cab, then was converted to a VS. Golf machine and eventually to a WWF Superstars cabinet.  For having such a life it is actually in really good shape.  The plywood sides are in perfect shape other than they are covered with two coats of black latex paint :(  I did scrape a bit of it off to make sure the blue paint was still there underneath and it still was.  The bezel is plexiglass, but I will be replacing that with a glass bezel I am sure as I don't want to mess with plexi for it.

It is going to be a fun project I hope.  I have my work cut out for me that is for sure.  Right now the plan is to restore it to a DK cabinet, at least cosmetically.  I do plan to put a PC in it and use it for a MAME cab for vertical games.  Then I will complete my scratch build for horizontal games.  Like I said, I have my work cut out for me and I have to do A LOT of research in order to even start with the insides.  In the mean time I will get to work on the exterior.   Wish me luck ;)

Sorry they are kind of crappy pictures.  Cell phone is all I had at the time.  I will take some better pictures tomorrow.   Any suggestions or advice is appreciated.


****UPDATE****** 4-26-2103

Here is the completed cab.  All of the progress pictures are on the following pages if you want to take a look.  :)



« Last Edit: April 27, 2013, 02:56:44 pm by TGov »

javeryh

  • Trade Count: (+1)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 7959
  • Last login:Today at 06:40:27 am
Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #1 on: September 02, 2012, 12:40:08 am »
Nice! I always love following these projects. You can take a look at my DK+ for some guidance if it would help. If you MAME it think about keeping the CP original-style. It is tempting to add another button...

You definitely have your work cut out for you!

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #2 on: September 02, 2012, 12:41:41 am »
Don't I know it :) Ya I know it is super tempting to add a couple more buttons, but if I add any they will be hidden for power, front end management, etc.

MacGyver

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 317
  • Last login:December 18, 2023, 12:49:00 am
    • Project Build
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #3 on: September 02, 2012, 01:39:01 am »
I remember seeing some nice modified DK artwork here that had some extra buttons, like you they were just going with vertical games and those don't take many buttons anyway.  Something like 800 with 2 or less, and 200 with 3 or more buttons (getting fewer as they go up; 30 with 4, 5 with 5, 3 with 6).
Remember to post pictures (sadly I forget to take during pictures all the time).

javeryh

  • Trade Count: (+1)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 7959
  • Last login:Today at 06:40:27 am
Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #4 on: September 02, 2012, 10:01:16 am »
Don't I know it :) Ya I know it is super tempting to add a couple more buttons, but if I add any they will be hidden for power, front end management, etc.

That is exactly what I did.  I have pause, exit and coin buttons hidden under the front lip of the CP (recessed) that aren't visible at all and you only know are there if I say something.  It works great.

I have a nice list of 30 or so games that are playable with most of them the ones you would want (Pac-man, DK, Dig Dug, Frogger, Mr. Do!, etc.).

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #5 on: September 02, 2012, 10:01:01 pm »
Well, I made a little bit of progress today.  I started stripping parts off of the cabinet to see what lies underneath.  Not too many surprises.  I knew the pieces that were there to attach the bezel for not factory so I stripped them off and got rid of the plexi bezel.  I took out the marquee and removed the incandescent bulbs and fixtures.  I plan to replace that with a florescent of some kind.  I took out the CP and fiddled around with it.  The player 1 joystick is shot, the rubber bushing inside was petrified.  So I switched it out with the P2 joystick so we could at least mess around with the WWF Superstars game in the meantime.  The CP is metal, so that will need replaced.  The coin door works and the mechanisms all work well.  It needs some TLC but I think I can get it restored to close to original.  The counter shows over 150,000 plays.  If that is anywhere near accurate, this machine has made some money over the years ;)

The latex pain is awful and not going to come off easily.  We have decided that we will paint over it with laquer based primer and get it sanded really smooth.  Then paint over that with what ever might work the best.  I think we can get a smooth finish that way and there really isn't any way to get the latex paint off of this thing without some serious work or money.  I am still not sure what model the monitor is or if it is original.  I couldn't find any definitive numbers on it.  Maybe somebody can identify it from the pictures.  The Jamma board looks really good and works great.  The WWF board looks brand new as well.

I also need to figure out how to rig up the bezel glass release.  The one that was on it wasn't original, so I am going to have to scrounge something up.  I wish I could find some good pictures of how that release works and how the bezel glass is held in place.  If anybody has any good links for that let me know :)

The next step is to research the monitor and figure out how to discharge it so we can get it out of there and into storage while the cab is finished up.  I also need to design the vertical mounting bracket for it.

Anyways, here are a ton of pics I took today with my good camera.


TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #6 on: September 02, 2012, 10:03:50 pm »
more....

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #7 on: September 02, 2012, 10:05:02 pm »
more....

DeLuSioNal29

  • Global Moderator
  • Trade Count: (+6)
  • Full Member
  • *****
  • Offline Offline
  • Posts: 4779
  • Last login:July 11, 2025, 09:17:44 am
  • Build the impossible -"There is no Spoon"
    • DeLuSioNaL's YouTube Videos
Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #8 on: September 02, 2012, 10:43:02 pm »
Glad to see you're doing a restore on DK. :-)

My buddy did one and put in DK II as well. Any interest in doing that instead?

D
Stop by my Youtube channel and leave a comment:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #9 on: September 02, 2012, 11:59:43 pm »
Not really as I plan on doing a MAME machine with it but I plan on keeping the outside of the cab as authentic as possible.  Since I am keeping the original monitor in it, I can always do a full conversion back to DK if I want to.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #10 on: September 03, 2012, 12:42:28 am »
So this thing has a Jamma board and I am assuming a harness in it.  So with that, how hard is it to get a signal from my PC to the monitor and have it display correctly?

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #11 on: September 03, 2012, 01:55:37 am »
also, can somebody tell me what the red box on the floor of the cabinet does?  It is hooked to the Jamma harness.

sdchown

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 32
  • Last login:January 24, 2013, 05:05:22 am
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #12 on: September 03, 2012, 01:58:27 am »
also, can somebody tell me what the red box on the floor of the cabinet does?  It is hooked to the Jamma harness.

What? The power supply?

- S

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #13 on: September 03, 2012, 02:03:20 am »
ya I guess I should have clarified.  I figured it was a power supply, so is it just supplying power to the board and the other one is going to the monitor?  I know I sound pretty ignorant.....that is because I am regarding this stuff.  I am a quick learner though ;)  I know the monitor only runs at 100 volts, so I know something is down converting to that, I just didn't know if the red box was doing that or not.

sdchown

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 32
  • Last login:January 24, 2013, 05:05:22 am
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #14 on: September 03, 2012, 04:51:32 am »
ya I guess I should have clarified.  I figured it was a power supply, so is it just supplying power to the board and the other one is going to the monitor?  I know I sound pretty ignorant.....that is because I am regarding this stuff.  I am a quick learner though ;)  I know the monitor only runs at 100 volts, so I know something is down converting to that, I just didn't know if the red box was doing that or not.

Jamma takes 12v and 5v from the Power Supply as far as I know.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #15 on: September 03, 2012, 11:06:34 pm »
I am curious if the monitor should be at the same angle in the vertical position as it is in the horizontal position now?  Anybody know?  After looking at a few restorations it seems like there are a couple of different angles people use.

DaOld Man

  • Trade Count: (+4)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 5158
  • Last login:May 24, 2025, 09:57:44 pm
  • Wheres my coffee?
    • Skenny's Outpost
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #16 on: September 04, 2012, 12:31:28 am »
I hate you.

Seriously, that is an excellent find! I have been looking for a DK cab for years now.
Good luck with your build, I will be watching this one for sure.
 :cheers:

javeryh

  • Trade Count: (+1)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 7959
  • Last login:Today at 06:40:27 am
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #17 on: September 04, 2012, 10:15:27 am »
I am curious if the monitor should be at the same angle in the vertical position as it is in the horizontal position now?  Anybody know?  After looking at a few restorations it seems like there are a couple of different angles people use.

You should be able to see the original location of the monitor frame mount (the bolt holes) on the inside of your cabinet.  At least that's what I used to line mine up...

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #18 on: September 04, 2012, 10:19:33 am »
Right on, I did see those but I wasn't sure that is what everybody was using.  Javeryh, would you mind if I PM you with some questions on a couple of things?  It looks like I am going to be basically doing the exact same thing you did with your build.

javeryh

  • Trade Count: (+1)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 7959
  • Last login:Today at 06:40:27 am
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #19 on: September 04, 2012, 11:31:29 am »
Right on, I did see those but I wasn't sure that is what everybody was using.  Javeryh, would you mind if I PM you with some questions on a couple of things?  It looks like I am going to be basically doing the exact same thing you did with your build.

Sure - I always love to help (assuming I can!).   :cheers:

astroone

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 96
  • Last login:January 10, 2020, 04:49:12 pm
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #20 on: September 04, 2012, 02:55:55 pm »
You got a good Score there for $200 With a Donkey Kong Rear Tag Plate  :cheers:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #21 on: September 04, 2012, 02:58:38 pm »
Thanks, I hope you are right.  It is going to be a lot of work, hopefully it will be worth it and the money invested ;)

astroone

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 96
  • Last login:January 10, 2020, 04:49:12 pm
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #22 on: September 04, 2012, 03:00:53 pm »
If you decide to do a restore the best place to get part's would Be http://www.arcade-museum.com/  and  ebay
« Last Edit: September 04, 2012, 03:03:29 pm by astroone »

PL1

  • Global Moderator
  • Trade Count: (+1)
  • Full Member
  • *****
  • Offline Offline
  • Posts: 9669
  • Last login:Today at 01:05:44 pm
  • Designated spam hunter
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #23 on: September 04, 2012, 04:57:16 pm »
More specifically, the KLOV forums trading post is here.

Parts for sale are listed here.  Parts for auction listed here.  Parts wanted listed here.

Several other DK parts sources:

Arcadeshop

Mike's Arcade


Scott

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #24 on: September 04, 2012, 04:59:00 pm »
I have been trying to register at the KLOV forum for a couple of days now and their registration page seems to be down.  I have tried it form home and work.

Thank you for the links and info!  :cheers:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #25 on: September 05, 2012, 01:32:12 am »
Well I have decided to keep the CP stock in the sense I will only have the jump button and the player 1 & 2 buttons.  If I need to play a game with 2 buttons it will just have to map the player 2 button to the 2nd button and reach over there.  It is going to make playing Contra a PIA  ;D

If a game needs 3 buttons then I will just have to wait until I get my other cab built sometime down the road.  I don't know of any vertical games that use three buttons anyways.

I also ordered an Omni2 joystick as I wanted a joystick that could switch from 4 way to 8 way easily.  The bottom of the stick is easy enough to reach through the coin door so it should work well.  I also have an idea for making the CP easy to lift in and out if that doesn't work too well.

On eBay today I bought an original CP overlay.  It looks to be in pretty good shape,  we will see.

Yvan256

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 1039
  • Last login:June 20, 2017, 08:35:41 am
    • Yvan256
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #26 on: September 05, 2012, 09:05:31 am »
Well I have decided to keep the CP stock in the sense I will only have the jump button and the player 1 & 2 buttons.  If I need to play a game with 2 buttons it will just have to map the player 2 button to the 2nd button and reach over there.  It is going to make playing Contra a PIA  ;D

If a game needs 3 buttons then I will just have to wait until I get my other cab built sometime down the road.  I don't know of any vertical games that use three buttons anyways.

I also ordered an Omni2 joystick as I wanted a joystick that could switch from 4 way to 8 way easily.  The bottom of the stick is easy enough to reach through the coin door so it should work well.  I also have an idea for making the CP easy to lift in and out if that doesn't work too well.

On eBay today I bought an original CP overlay.  It looks to be in pretty good shape,  we will see.

Couldn't you also simply set aside the original control panel for a future complete restoration and make a new one for your MAME cabinet?

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #27 on: September 05, 2012, 09:37:02 am »
Ya, you are probably right.  I will have to think about it, but I just ordered my buttons last night  :banghead:   :laugh2:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #28 on: September 06, 2012, 01:32:59 pm »
Scrounged up a older computer yesterday.  Core 2 Duo with 2gb of Memory so it should run all of the older vertical games just fine.  I started setting up MAME and finding working roms.  Also with this Dell monitor turned sideways, I can start laying out my front end in MaLa.  I ordered an SSD last night to put XP Pro on for the boot drive to speed things up.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #29 on: September 08, 2012, 10:14:12 pm »
So I have been debating a bit with myself on how I want to approach this build.  Initially I was thinking a straight MAME cabinet with PC and joystick/button controller using Soft15hz for the original monitor.  I then was thinking about restoring to an original cab with Nintendo wiring and DK PCB.  If I did this I would most likely sell the cabinet after a short time.  As much as I love DK, I don't have another cabinet yet and don't have the room for more than two cabinets.  So, I would hate to go to all of the work to sell it off so quickly, and who knows if I would make my money back or not.

My next option was to keep the Jamma harness and using a JPAC to interface with the PC.  That way I would still have a cab that would be MAME capable, but also I could throw any JAMMA board in there if I needed or wanted to.  I also figured that I could get a Jamma to DK adapter and even put an original DK PCB in there if I wanted to sell it.  This would give me the flexiblilty of having the MAME setup now and an easy way to convert it back to DK and it also will have the option to be any Jamma game for that matter (vertical).

I already ordered a replacement JAMMA harness as this one is patched in several places and kind of ragged.  They are cheap enough.

Thoughts on the matter?

I also wad digging around in the cabinet today and it looks like I won't need a power converter for the monitor as there is already one in there since it is Jamma.  One less thing to worry about.  Also the video inverter board is on there and in good working order.

mgb

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 3500
  • Last login:January 06, 2025, 09:39:00 pm
  • North East, US
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #30 on: September 10, 2012, 11:30:11 pm »
Scrounged up a older computer yesterday.  Core 2 Duo with 2gb of Memory so it should run all of the older vertical games just fine.  I started setting up MAME and finding working roms.  Also with this Dell monitor turned sideways, I can start laying out my front end in MaLa.  I ordered an SSD last night to put XP Pro on for the boot drive to speed things up.

I'm running about 600 games, mostly verticals, all the classics plus a bunch of 90s vertical shmups and a good number of horizontals all with a pc at a lower spec and they run fine.
My mame pc spec is a p4 1.6G with 512M of memory


So I have been debating a bit with myself on how I want to approach this build.  Initially I was thinking a straight MAME cabinet with PC and joystick/button controller using Soft15hz for the original monitor.  I then was thinking about restoring to an original cab with Nintendo wiring and DK PCB.  If I did this I would most likely sell the cabinet after a short time.  As much as I love DK, I don't have another cabinet yet and don't have the room for more than two cabinets.  So, I would hate to go to all of the work to sell it off so quickly, and who knows if I would make my money back or not.

My next option was to keep the Jamma harness and using a JPAC to interface with the PC.  That way I would still have a cab that would be MAME capable, but also I could throw any JAMMA board in there if I needed or wanted to.  I also figured that I could get a Jamma to DK adapter and even put an original DK PCB in there if I wanted to sell it.  This would give me the flexiblilty of having the MAME setup now and an easy way to convert it back to DK and it also will have the option to be any Jamma game for that matter (vertical).

I already ordered a replacement JAMMA harness as this one is patched in several places and kind of ragged.  They are cheap enough.

Thoughts on the matter?

I also wad digging around in the cabinet today and it looks like I won't need a power converter for the monitor as there is already one in there since it is Jamma.  One less thing to worry about.  Also the video inverter board is on there and in good working order.

I like the idea of going with a jamma wiring and interfacing the mame machine through a jpac. While keeping the outside an original DK. though I think I would want more than one button so maybe build one dk themed cp with extra buttons (but tie them nice into the original artwork) and then you can always have the fun project later on of building an original dk cp should you wanna sell it.
I think the jamma wiring will give you the most versatility.

I see you have a sanyo 20ez and I see it has the video inverter board. It must also have the voltage converter. Just to clarify because I see you questioned elsewhere about the red box at the bottom of the cabinet.
That red box is the power supply (5v and 12v) for your jamm board, it has nothing to do with the monitor. The large transformr to the right of it is the monitors isolation transformer.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #31 on: September 10, 2012, 11:34:54 pm »
Ya I figured all of that out regarding the voltages the other day when finally getting some time with the cabinet.  So that is good that it is all already in there so I don't have to really mess with it.  I do plan on making two CP's for this, an original and a Custom CP with 3 'jump' buttons for various games, I am also putting a 4 way/ 8 way switchable joystick in there.  I plan on using molex style connectors to make the CP easy to swap out of the Jamma harness.  Initially I will just have the Standard DK CP as that is what I have right now, but I will eventually build the other CP.

I have all of the parts I need now on order or already in my hands except for the paint, side art, t-molding and a bezel.  I am having a hard time finding a bezel that isn't scratched all to hell.  I would like to keep most of the parts original, but that might not be an option on the bezel.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #32 on: September 13, 2012, 11:18:15 am »
Not much to update here.  I plan on taking the monitor out tonight and trying the Citristrip gel on the latex paint to see if it will lift it off.  Fingers crossed.

In the mean time, I received my parts order from Groovy Game Gear.  I didn't want to wait around to get the cabinet done so I made my ghetto cade and fired up MAME :)  The leaf switches are really nice and super responsive.   I am having trouble in MAME saving the input for the down direction on the joystick.  Even if I edit it in the controller.ini file it still changes it to a different input.   I will even change it inside mame and as soon as I exit and go back it, the down is remapped to another button that is not being used.  Weird.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #33 on: September 13, 2012, 11:57:36 pm »
I got the cabinet loaded up in the van tonight to bring home tomorrow so I can actually get some work done.  I like having it in our race shop, but it is a pain driving out there to work on it.  So, until I need something out there I will keep it here.

I removed the monitor and also applied a little bit of the Citristrip to see if it was going to work.  What do you know it took the 2 layers of latex right of right down to the laminate side.  It is going to take my elbow grease but I think I can get it all off of there and that will give me a much smoother surface to work with for the repaint.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #34 on: September 14, 2012, 11:28:26 pm »
Well, what can I say other than Citristrip is some awesome stuff.  I got the cabinet home tonight so I could actually work on it.  I put on a thin coat of Citristrip and let it set for about an hour.  Then I took a heavy duty metal paint scraper and went to work.  It took me about 1.5 - 2 hours to strip one side completely and give it a light sanding.  I now have a nice surface to work with.  It needs some bondo in a few places, but overall the laminate is in really good shape other than having a lot of sanding marks.   I flipped it over and applied a good coat of Citristrip to the other side and I am going to let it sit over night.  One thing I really like about the Citristrip is that it doesn't turn the latex in to a sticky goop, it is more of a dry rubbery mass.  It doesn't make as much of a mess that way.

Even in its faded scratched up state, the light blue looks so much better than black ;)


TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #35 on: September 15, 2012, 01:36:07 pm »
I spent the rainy morning stripping the other side of the cabinet.  It isn't in as good of shape as the first side, but nothing a little bondo/body putty can't fix.  I will try to strip the front tonight.   In the meantime I received my marquee in the mail.  It isn't in as good of shape as I would have hoped, but what are you going to do?  It was a vague description on eBay and I should have asked for backlit pictures.  Oh well, lesson learned.  It will be ok for now.  I installed my cheap under counter flourescent and lined the inside with foil tape to help reflect the light.  I think it turned out pretty good and there seems to be decent coverage on the light.  Overall I am happy with how that turned out.  :)

More later.


TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #36 on: September 18, 2012, 12:26:56 pm »
I was messing around with the CP layout today and I think I have decided to put the admin buttons on the CP as I don't want to drill into my cabinet just in case I ever want to convert it back to a stand alone cab.  I think this layout works pretty well and doesn't look too gaudy  ;D

I still plan on making a second CP that will be able to plug right into the Jamma harness.  I already have nice original CP artwork/plexi for that.

Opinions?

Louis Tully

  • Trade Count: (+5)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 1800
  • Last login:February 13, 2015, 09:41:03 pm
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #37 on: September 18, 2012, 08:19:44 pm »
.
« Last Edit: February 12, 2015, 09:37:24 am by Louis Tully »

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Looks like I stumbled upon a Donkey Kong cabinet, new project.
« Reply #38 on: September 18, 2012, 08:50:44 pm »
If I didn't already have the orange buttons that might work.   :D

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
I started putting the body putty on the sides today and getting the edges shaped up.  I finished up one side and it looks pretty good.  For the putty I used auto body putty and glaze putty for the sides.  I hope to get the other side done tomorrow.  Sherwin Williams was having a sale this weekend so I stopped by and had them mix some oil based satin enamel.  They color matched the blue from the piece that attaches to the top of the front panel.  I figured that piece had probably seen the least amount of direct light over the last 30 years so the color was probably pretty close to the original blue.  The color they game me appears to be spot on, we will see once I start painting.  It was a good deal at $14 for a quart of it, it usually runs about $25 a quart.   I plan on spraying it so I wanted oil based for sure and oil based enamel will dry nice and hard so I don't have to worry as much about scratching it like latex.

It is coming along.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Work is coming along slowly.  I have both sides ready to prime, but I am going to wait for the humidity to die down a bit before I spray it.  It might be a week or two on that one.   Yesterday I spent about two hours sandblasting the coin door.  It looks much better now and is ready to paint after I fix a little dent in the top of the door.

My brother has a CNC machine so we played around with cutting out the control panel.  It is still new to him and I am not familiar with the machine, so we had some screw ups and I didn't have every measurement I needed.   You can see the sample pieces being cut out though ;)

The PC has been shelled and I have Hyperspin working great, so the PC side of things is nearly done and ready to go.  My JPAC will hopefully be here any day now and I can start messing around with figuring the wiring out.


brewerdude

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 28
  • Last login:March 22, 2019, 01:35:37 am
Looks great!  Whoever covered all that beautiful DK blue, must be kicking them-self right now.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
I am not sure who did cover it or when it was but they did a really crappy job of it ;)

Last night I fixed the dent in the coin door and got it sprayed with some Rustoleum Textured black paint.  It looks much better now.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
My awesome brother delivered some presents for me tonight!  He did a great job building me a new bottom bezel and CP retainer and also routing out the CP and the speaker panel with the CNC.  He even built in the mounting blocks for them.  I think they look great and everything fits like a glove!  Time to get everything finished up on the body work front and get this thing ready to paint!!!

« Last Edit: October 10, 2012, 10:54:22 pm by TGov »

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
We got the first coat of primer on today and worked on fixing all of the little places I missed with some glaze putty.  Luckily I had my dad there to help me out on this part as he has been doing body work on cars for 40 years, so he knows what he is doing ;)

All in all it looks so much better with the primer on it and has really made me excited to get the paint on there and get it finished up!


DLinkOZ

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 125
  • Last login:March 22, 2017, 08:12:46 am
    • The DaveCade
Re: Donkey Kong cabinet, new project. (Update 11-3-12)
« Reply #45 on: November 03, 2012, 11:08:50 pm »
I had a similar restoration - kept it externally accurate (mostly) but I kept the VS control panel.  Internally, I justified not doing a proper restoration by telling myself that I was keeping things with the Nintendo theme.  That is, I put an old NES inside and wired up the pair of controllers to the VS control panel.  I still need to modify the DK cpo to match the VS layout, but that's kind of a C list task right now.

http://album.oesm.org/arcade/Donkey%20Kong/2012-10-14/index.html#149675_505866832771992_1010274754_n.jpg

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. (Update 11-3-12)
« Reply #46 on: November 26, 2012, 03:52:13 pm »
Found some more rough spots so we re-glazed and sanded it down and re-primered the cab.  It is ready for paint now :)  Hopefully this week.  My brother is also building me a new base for the cab as this one is about shot and not square on the bottom.   :cheers:


DaOld Man

  • Trade Count: (+4)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 5158
  • Last login:May 24, 2025, 09:57:44 pm
  • Wheres my coffee?
    • Skenny's Outpost
Re: Donkey Kong cabinet, new project. (Update 11-27-12)
« Reply #47 on: November 26, 2012, 04:54:56 pm »
Looking good!!

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. (Update 11-27-12)
« Reply #48 on: March 14, 2013, 08:36:51 pm »
Well with the weather warming up I have finally gotten around to painting this beast.  First coat of oil based enamel is on.  I had a run on the far side so I am going to have to wait for it to dry a few days and sand it out and respray.  I have been busy the last couple of months bringing a Space Duel back from the dead.   So this one got put on the back burner.   I really hope to get this done by the time the month is out.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. (Update 4-08-13)
« Reply #49 on: April 08, 2013, 11:05:45 pm »
Slowly making more progress.   My machines on location and the Alladin's Choice restore I am doing for a friend are taking up all of my time.  The cab is now fully painted, but I don't have a picture of it yet.  I finished up the control panel tonight and wired it all up.  I need to get a hold of some molex connectors though for the CP.  My brother built me a new base for the cab since mine was shot.  I think he did a great job!

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. (Update 4-08-13)
« Reply #50 on: April 22, 2013, 02:19:10 pm »
Well, we are almost there! The cab is complete, the monitor is working and looks great (love the EZ20's).  Got the computer installed, jamma harness is installed, jpac installed........and then the controls wouldn't register inside windows........great.

So, I threw in a NeoGeo 1 slot PCB I had lying around to test my controls and they all worked just fine.  Hours and hours later of fighting with the JPAC trying to get it to work i broke down, removed the CP wiring and wired it up using a 36 button USB controller board I had lying around.  Hooked it up, boom, controls are now working...YAY!

Next is the sound.  I had purchased a great little audio amp PCB kit from electronickits.com and put it together.

http://electronickits.com/kit/complete/ampl/k143.htm

I had been searching around for a power supply for it for a while now.  It needs 8-18 volts at 1-2 amps.  While working in the cab I noticed my switching power supply happened to have a 12v 2amp line on it.  Perfect!  Hooked it up, works great!!  Nice clear sound coming out of the DK speaker.  Shut the computer down as I had to go to dinner.   Came back a few hours later.......the computer won't boot up now.  Ugghh.

Worked on it for over two hours....it won't even boot the bios.  Sooooo.....either it is a vid card issue or a motherboard.  I am leaning towards mother board at this point as all it will do is power the fans on, nothing after that.

Luckily I have a buddy who is giving me a nice Core 2 Duo machine that will work great.  I hope to have it all up and running by this evening.

As for the cab itself, I think it turned out really good considering what it looked like when I started.  The colors in the pictures are all off due to the light and the cell phone camera.  I will take some better pictures once I get it all up and running.  I did use the cheap side art, and while it looks good, I will eventually put some better screen printed artwork on it.  The oil based satin paint looks great and has a finish just like the original laminate.

Sorry, that was a rambling post!!!

Drnick

  • Trade Count: (+2)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 1642
  • Last login:June 21, 2024, 03:32:31 pm
  • Plodding Through Life
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #51 on: April 22, 2013, 02:24:28 pm »
Looks pretty damned authentic to me  :applaud:

Maximus

  • Trade Count: (+2)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 1391
  • Last login:May 26, 2017, 05:32:05 pm
  • Plans are for fools!!!!
    • Arcade Icons
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #52 on: April 22, 2013, 02:36:35 pm »
Looks great, congrats on your lovely minty fresh new DK!!

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #53 on: April 22, 2013, 10:31:16 pm »
Thanks gents!

alteredgrafix

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 10
  • Last login:June 12, 2013, 10:57:01 am
  • Roads? Where we're going, we don't need... roads.
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #54 on: April 26, 2013, 06:43:01 pm »
Looks great!!!! Have fun seeing how high you can get!
World Cup 94 pinball, Fix-It Felix Jr. Replica

sabreerbasAlpha

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 253
  • Last login:February 13, 2017, 07:28:29 pm
  • Remember those big 10ps?
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #55 on: April 26, 2013, 06:47:24 pm »
Without a doubt. The DK Blue cab is the king of all Cabs. Looking sweet my friend and a really nice job. So much hard work by the looks of it. You must be really proud of her... :notworthy:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #56 on: April 26, 2013, 07:07:07 pm »
Thanks guys  :)

Ya, it was a ton of work but it was worth it.  The only thing I don't like about it right now is the Omni 2 joystick.  I really don't care for the feel and it keeps sticking from time to time.  The switching from 4 to 8 way is nice but is annoying at the same time.  So I ordered a JLF with an octagonal restrictor and feel how that goes.

Love the Sanyo, such a great monitor.

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. ALMOST COMPLETE!! (4-22-13)
« Reply #57 on: April 27, 2013, 02:49:42 pm »
A few more pictures using a better camera :)

Maximus

  • Trade Count: (+2)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 1391
  • Last login:May 26, 2017, 05:32:05 pm
  • Plans are for fools!!!!
    • Arcade Icons
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #58 on: April 28, 2013, 12:29:18 pm »
Looks great now I'm jealous I'm still waiting for my flyback for my Sanyo. My DK is just a glorified paper weight at the moment lol

Gamester

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 483
  • Last login:March 01, 2019, 03:00:10 pm
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #59 on: April 28, 2013, 02:37:09 pm »
Looks awesome!  Makes me want to do a restore.  Maybe after I finish and recover from the pin build I'll consider it.  Still have a slot or two available on the wall in my game room that may need filling.  ;)

So what's next on the list?  Time to get back to your hybrid pin-cade thingamajigger?
Current Project:                                                       First Project:


Mr Wilson

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 182
  • Last login:August 14, 2018, 01:24:44 pm
  • it never ends!!!!
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #60 on: April 28, 2013, 04:32:45 pm »
awesome!  :applaud: i wish i could find a DK in the classifieds here in the UK,i think my next project will be a Restoration of some kind

sabreerbasAlpha

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 253
  • Last login:February 13, 2017, 07:28:29 pm
  • Remember those big 10ps?
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #61 on: April 28, 2013, 06:01:32 pm »
awesome!  :applaud: i wish i could find a DK in the classifieds here in the UK,i think my next project will be a Restoration of some kind

Build one from scratch. :angel: You can do it  :cheers:

TGov

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 223
  • Last login:March 21, 2017, 02:07:54 pm
  • I want to build my own arcade controls!
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #62 on: April 29, 2013, 12:33:39 am »
Thanks guys.  Up next is selling my Space Duel that is next to the DK there and buying a pin to replace it.  While I would love to do the virtual pin thing, i just don't have the time or energy to devote to building it and setting it all up :)  I am hoping to find a Jackbot :)

mgb

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 3500
  • Last login:January 06, 2025, 09:39:00 pm
  • North East, US
Re: Donkey Kong cabinet, new project. COMPLETED!! (4-26-13)
« Reply #63 on: April 29, 2013, 07:59:40 am »
The DK looks awesome
