Pit Boss Nanao / Kaga/TSK KZ-9H monitor
« on: March 14, 2006, 12:24:00 am »
I need the schemaics for this merit Pit Boss monitor if anyone has them.  Thanks.
Logged

Ken Layton

  • Guru
  • Trade Count: (+1)
  • Full Member
  • ****
  • Offline Offline
  • Posts: 7061
  • Last login:October 12, 2021, 12:25:59 am
  • Technician
Re: Pit Boss Nanao / Kaga/TSK KZ-9H monitor
« Reply #1 on: March 11, 2007, 12:20:16 pm »
I have just scanned & cleaned up the schematic to this monitor. I have emailed it to arcarc.xmission.com for conversion into a pdf file so they can post it there for free download. Should be posted there in the next few days. I am in the process of writing a repair guide to this model since I just found all of my old notes on this model.
Logged

Ken Layton

  • Guru
  • Trade Count: (+1)
  • Full Member
  • ****
  • Offline Offline
  • Posts: 7061
  • Last login:October 12, 2021, 12:25:59 am
  • Technician
Re: Pit Boss Nanao / Kaga/TSK KZ-9H monitor
« Reply #2 on: March 13, 2007, 12:18:32 am »
Schematic is now posted.
Logged
