Author Topic: Starfighter Build  (Read 14296 times)

0 Members and 1 Guest are viewing this topic.

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Starfighter Build
« on: March 20, 2016, 08:15:00 pm »
Build from Rogue Synapse plans online... Got everything drafted up and tacked together.  Probably work on the base this week, getting it finished up.  Then tackle the bezel.  Haven't decided on hardware yet, but plenty of 22-24" LCD available for cheap so will probably go that route.  I have a couple dual-core atom mini-pc's that would probably work well for this one.


yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #1 on: March 20, 2016, 11:11:03 pm »
Are you going to run just the Starfighter game?
***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #2 on: March 21, 2016, 12:18:04 am »
Are you going to run just the Starfighter game?

Yup.  Just starfighter.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #3 on: March 21, 2016, 12:18:54 am »
Cool. Interested to see how you handle the control scheme. Good luck!
***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #4 on: March 21, 2016, 04:17:23 pm »
I'm thinking I might want to go 24" monitor here. That's a 22" and the extra inch all around might fill it out better.


Sent from my iPhone using Tapatalk

dmckean

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 729
  • Last login:January 13, 2024, 08:50:41 pm
Re: Starfighter Build
« Reply #5 on: March 21, 2016, 06:35:18 pm »
I would measure and use the largest monitor that will fit.

harveybirdman

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 2538
  • Last login:February 19, 2024, 12:40:25 pm
  • SHMUP'EM
Re: Starfighter Build
« Reply #6 on: March 21, 2016, 06:46:09 pm »
You will never defeat Xur and th Kodan Armada on a 22in screen bruh.

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #7 on: March 21, 2016, 07:30:05 pm »
27" samsung has smaller bezel which can hide behind the raised bezel.  27" it is... off to ebay.

dmckean

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 729
  • Last login:January 13, 2024, 08:50:41 pm
Re: Starfighter Build
« Reply #8 on: March 21, 2016, 07:50:14 pm »
That should work great.

A 27" 16:9 screen should give you a 18.5" 4:3 image which is pretty much exactly the same size the original cabinet.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #9 on: March 21, 2016, 08:36:29 pm »
Alex Rogan saved the universe on a 19" CRT.
***Build what you dig, bro. Build what you dig.***

wp34

  • Trade Count: (+3)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 4794
  • Last login:April 10, 2022, 09:48:19 pm
Re: Starfighter Build
« Reply #10 on: March 21, 2016, 09:12:56 pm »
Cool build.  I used to play the heck out of The Last Star Fighter on the Atari 800.  What version of the game are you putting on your cabinet?


fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #11 on: March 21, 2016, 09:14:52 pm »
Cool build.  I used to play the heck out of The Last Star Fighter on the Atari 800.  What version of the game are you putting on your cabinet?



The one released by rogue synapse.  Going to work to put together as much as the original [movie] playability as possible, fabricating joystick and t-grip button handle, rocker switches and all that from everything I've researched on it in the last few months.

wp34

  • Trade Count: (+3)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 4794
  • Last login:April 10, 2022, 09:48:19 pm
Re: Starfighter Build
« Reply #12 on: March 21, 2016, 09:22:36 pm »
Awesome!  This should be a fun one to watch.   :cheers:

Cool build.  I used to play the heck out of The Last Star Fighter on the Atari 800.  What version of the game are you putting on your cabinet?



The one released by rogue synapse.  Going to work to put together as much as the original [movie] playability as possible, fabricating joystick and t-grip button handle, rocker switches and all that from everything I've researched on it in the last few months.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #13 on: March 21, 2016, 09:43:25 pm »
Can't wait to see how you do the t-grip button handle.
***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #14 on: March 21, 2016, 09:46:29 pm »
I can't really find anything that would work for it out the box, so my initial thinking of what I'm going to try is maybe a 2" hallowed out wooden dowel and painstaking hours of working it with tabletop sanding wheel - probably screwing it up 3-5 times before I get it right.  Attach it to another hollowed dowel which attaches to the original joystick handle, wires run through the center.

Now the button... I'm sure I'll spend $50 on various $2 buttons online until I find the perfect one that works heh.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #15 on: March 21, 2016, 10:24:25 pm »
I can't really find anything that would work for it out the box, so my initial thinking of what I'm going to try is maybe a 2" hallowed out wooden dowel and painstaking hours of working it with tabletop sanding wheel - probably screwing it up 3-5 times before I get it right.  Attach it to another hollowed dowel which attaches to the original joystick handle, wires run through the center.

Now the button... I'm sure I'll spend $50 on various $2 buttons online until I find the perfect one that works heh.
I always wondered about maybe adapting a shifter handle like you see in the car.
***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #16 on: March 21, 2016, 10:25:46 pm »
If you or anyone has ideas that might work I'm definitely up for trying them.  I also peruse local pawn shops, flea markets and other stuff to see if anything grabs me by sight as well.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #17 on: March 21, 2016, 10:26:41 pm »
Mount this on top of a digital joystick..

***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #18 on: March 21, 2016, 10:33:13 pm »
hehe that's actually pretty close.  Button is a hair off from the original size, but if I could fabricate/modify/mold a simple cover for it that's a hair larger it would probably be just about spot on!

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #19 on: March 21, 2016, 10:58:54 pm »
I realized that I didn't account for the 4" height of the casters. That's why there's a gap in the top of the base there. Going to have to remove the top and cut some out.

Rounded out some of the cabinet edges and CP as well.

As I stand here covered in sawdust, building one cab with a second unfinished next to it and watching X-Files reruns on a third, it occurs to me that this might very well be the geekiest place on earth right now.



Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #20 on: March 22, 2016, 12:07:19 am »
This is turning out to be a much tougher task than I pictured in my head. Lol.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #21 on: March 22, 2016, 02:31:37 pm »
Not sure how I made this mistake. Maybe not accounting for the original 25" CRT?  There seems to be about 4" of extra space. Could probably use 1.5" instead of 3/4 or 1", adjust the angles and make up 2-3" at the bottom. Maybe drop the location of the monitor 2" too and use the extra space at top for speakers. Or I could cut 4" out the top of the cab and rebuild the marquee area. Hrmmmm.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #22 on: March 22, 2016, 02:40:38 pm »


sorry for sideways pic.. not mine from rogue synapse's build.

Going to build from the CP up... will start on the lights and all that, get them done right and then get the bezel/monitor spaced right and cut the excess out the top of the cab and rebuild the marquee.  The measurements on the back top of the cab won't be quiet exact from the blueprints, but oh well.  I highly doubt anyone would notice that.

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #23 on: March 22, 2016, 03:01:29 pm »
I see where I screwed up!

The CP has an angle to it the same as the sides of the cab.  See how the where the joysticks bolt in, it dips down and that part is level, but the rest is angled about 15deg or so.  I made mine level.   My CP joystick surfaces are 10" deep.  Making them level puts them up to 13" deep at an angle.  That puts everything on the backboard 4" higher, which should account for the differences.
« Last Edit: March 22, 2016, 03:04:02 pm by fryed_1 »

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #24 on: March 22, 2016, 05:09:06 pm »
This should be strong and more realistic. Don't think I'll have to chop the top now.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #25 on: March 22, 2016, 08:38:57 pm »
Cut the recessed joystick pass out and looks much better now.


Sent from my iPhone using Tapatalk

harveybirdman

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 2538
  • Last login:February 19, 2024, 12:40:25 pm
  • SHMUP'EM
Re: Starfighter Build
« Reply #26 on: March 22, 2016, 09:52:11 pm »
You don't realize it but your starting a bunch of projects before finishing others and propensity to get better and better reminds me a lot of a really good poster that used to buzz around here.

Keep up the good work!!!  :cheers:




... just don't theme a cab after Jim Morrison  ;)

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #27 on: March 22, 2016, 09:59:11 pm »
You don't realize it but your starting a bunch of projects before finishing others and propensity to get better and better reminds me a lot of a really good poster that used to buzz around here.

Keep up the good work!!!  :cheers:




... just don't theme a cab after Jim Morrison  ;)

Yeah I'm kind of waiting to do vinyl/sticker work on the kids' cab before I do it on mine so I can work out the bugs before getting to mine.  This one... drank too many beers the other night and woke up with side panels and marquee cut out so figured I might as well finish it.

yotsuya

  • Trade Count: (+21)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 19955
  • Last login:Yesterday at 10:19:17 pm
  • 2014 UCA Winner, 2014, 2015, 2016 ZapCon Winner
    • forum.arcadecontrols.com/index.php/topic,137636.msg1420628.html
Re: Starfighter Build
« Reply #28 on: March 22, 2016, 10:02:23 pm »
This one... drank too many beers the other night and woke up with side panels and marquee cut out so figured I might as well finish it.

That's pretty damn awesome.

"I swear, babe, I was watching TV and tipping back a cold one, then next thing I knew, it was there...."
***Build what you dig, bro. Build what you dig.***

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #29 on: March 22, 2016, 10:08:43 pm »
Well she doesn't buy the.. "Honey there were 3 sheets of wood taking up room in the garage.  This is a much more efficient way to store wood!"... argument anymore..

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #30 on: March 22, 2016, 10:44:14 pm »
These are done now. If I had sticks could toss in a couple spare buttons and an old lcd and actually have it playable now.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #31 on: March 23, 2016, 01:34:35 pm »
Building a parts list and starting ordering.

ipac2 of course will make things easy to configure and supported.

Minigrip sticks should work to rewire and make new handles for as the wires are easily run through the center of the stick and out the bottom.  I'm going to try to find some of the car shifters posted above at reasonable prices for the targeting and either make or search out old joysticks where I can setup a single plunger-style switch on the top for the tracking left stick.




I'm going to try these momentary single-pole rockers for weapons selection.  Spring loaded so they pop back in to place.
http://www.webstaurantstore.com/bunn-02628-0000-momentary-start-rocker-switch-for-coffee-tea-brewers/233026280000.html?utm_source=Google&utm_medium=cpc&utm_campaign=GoogleShopping&gclid=CjwKEAjw_ci3BRDSvfjortr--DQSJADU8f2j5sQyQzylEATIYnsXaPlpVJF6_6uTn3THdm9zWj6M6BoCJnjw_wcB




I ordered a RPI3 and thinking about going win10 iot stripped down with custom boot screens and startup script to boot right in to starfighter exe.  If this doesn't work, I'll use one of the Atom mini-pc's.  Also debating using a laptop again - one of the great things about using them is built-in cooling to a degree, plus you can set it to shut down after 1min on battery and power on when power is detected, which makes the startup/shutdown procedure pretty painless and no need for key combinations or complicated procedures.

Ebayed a Dell 27" 16:9 LCD - $90 shipped no base or mounting hardware, perfect for this.

Dayton amp.  Ordered this for the last build and while expensive at $100, it's ready to install and does so easily, 60wpc and looks great.  I've spun it up on my other cab with the same amp with and without the sub and there's very little difference, so I think a decent pair of 5-6.5" all-range, hidden on the top left and right of the monitor bezel will work great.



7074 Lexan for the glass of course and laminate for the sides/back/base.


I'm debating LED's in the panel under the bezel.  Not sure if I want it to look "too modern" and putting some colored light tubes or whatever they're called that transmit light by shining on the other end.  Some of those with a light and reflective tape behind it behind that area might actually give it a more authentic look.


The game is built to allow for a death blossom button or combo if you so want to use it.  I know it's not in the movie version (or any others) but I'm thinking about adding a dedicated death blossom button.  I've watched the movie a couple dozen times over the last few months and done a lot of pausing and screenshotting, but it appears it would have been around armrest level of his right hand when sitting in the cockpit.  If it were a spring-loaded door, maybe just below the targeting stick... who knows.  Make it and go through some bubble gum and stick it in various spots before I decide... If I did, would likely do a big red pushbutton below a spring loaded door.



Looks to be Happ over/under coin door.  Around $80-90 new, as low as $30 with shipping on ebay.  Will be setup free play or coin release to drop coin.






I don't think any other administrative buttons would be needed.  Volume is covered, 3x weapons selection rockers, 2x joysticks with fire buttons, coin door, glass and plastic... just need to figure out the parts and lighting for this area:


fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #32 on: March 23, 2016, 07:28:01 pm »
Had to put this on for motivation.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #33 on: March 24, 2016, 05:54:57 pm »
My 4 girls are earning their Girl Scout woodworking badges helping me.  They did 100% of the putty and sanding work here.


Sent from my iPhone using Tapatalk

Slippyblade

  • Trade Count: (+2)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 3167
  • Last login:November 16, 2023, 11:39:51 am
  • And to the death god we say, "Not today!"
Re: Starfighter Build
« Reply #34 on: March 24, 2016, 06:50:17 pm »
My 4 girls are earning their Girl Scout woodworking badges helping me.  They did 100% of the putty and sanding work here.

Way to go including the family!  That's awesome.

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #35 on: March 25, 2016, 03:25:13 pm »
This was the only graphic that wasn't already available. Even with my limited illustrator skills, I think it'll work.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #36 on: March 26, 2016, 12:41:58 am »
Think I got all the graphics mocked up and the right size for printing.


Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #37 on: March 28, 2016, 05:01:33 pm »
Pretty much on hold now until some parts start arriving. Graphics printed to scale and fit good so they're ready for sending off. Monitor and controls on the way. Have some various LED ordered to see what fits in the display right before I order all of them. Bezel cut out just needs a monitor under it to finish it off.

Guess I could always start finishing one of the other cabs in here!




Sent from my iPhone using Tapatalk

fryed_1

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 88
  • Last login:June 22, 2017, 11:15:35 pm
  • I want to build my own arcade controls!
Re: Starfighter Build
« Reply #38 on: April 20, 2016, 05:28:58 pm »
No new pics yet, but Disney trip is done and I'm authorized to finish it.

So ordered a crapton of LED 3mm and 5mm plus housings for them - good thing they're cheap! -.  PacLED64, ipac and joysticks on the way.  27" LCD is here (samsung) but I need to buy another sheet of wood first to cut out a new panel for it as well as some real bezel-quality wood rather than cutting 2x2 in half like above.  I got 3x rocker switches from a restaurant supply place - single throw momentary, so those should work good.  I got 3x 1" push on/off green/red/yellow square power on/off buttons that will go in the display below the monitor where the square LED's are.  Instead of a powerswitch in the back, I'm going to use these to power up the cab.  Maybe monitor/computer, lights and sound.

Started grinding down dowels and other chunks of wood to try to make controls - nothing great yet but it's getting there.  Coin door on the way too.  Most everything should be here by fri/sat to at least make it playable.

dmckean

  • Trade Count: (0)
  • Full Member
  • ***
  • Offline Offline
  • Posts: 729
  • Last login:January 13, 2024, 08:50:41 pm
Re: Starfighter Build
« Reply #39 on: April 20, 2016, 06:55:52 pm »
Sweet! I was just thinking about this build yesterday. I can't wait to see how it turns out.
